Structural Advantages:

• High-quality aluminum alloy cast housing, adaptable to universal mounting configurations in all directions.
• Excellent thermal conductivity of the body.
• Available in 9 frame sizes, from 025 to 130, with power transmission ranging from 60W to 7.5KW.
• Wide speed ratio range, with each frame offering 11 reduction ratios from 7.5:1 to 100:1.
• Precision-ground, hardened worm gear transmission for high efficiency and substantial output torque.
• Smooth operation with low noise, suitable for continuous long-term use in harsh environments.
• Lightweight yet mechanically robust.

Material Composition:

• Housing: Aluminum alloy (frame sizes: 025–090); cast iron (frame sizes: 110–130).
• Worm: 20Cr steel, treated with carbon-nitrogen co-diffusion (retaining a tooth surface hardness of HRC60 after precision grinding, with a hardened layer thickness >0.5mm).
• Worm Wheel: Available in two material options: a specially formulated wear-resistant nickel bronze or the commonly used 94 copper.

Surface Coating:

• The surface undergoes shot blasting followed by a special anti-corrosion treatment, preserving a silver-white metallic finish while resisting corrosion from organic solvents such as gasoline and xylene.
• Two color options available for the exterior: baked enamel in RAL9002 gray or RAL5010 blue.
